| Component | Weight | Cost | |
|---|---|---|---|
|
Main Die Block H13 Tool Steel |
372.0 kg | 10114.0 | ▼ |
|
Component Info
Dimensions
580.0x430.0x190.0 mm
Material
372 kg × 5
1860
Machining
Machining Subtotal
3575
Heat Treatment
Hardening & Tempering
930
Surface Treatment
Polishing & Nitriding
670
Component Total
10114.0
|
|||
|
Upper Punch H13 Tool Steel |
30.0 kg | 704.0 | ▼ |
|
Component Info
Dimensions
-
Material
30 kg × 5
150
Machining
Machining Subtotal
210
Heat Treatment
Hardening & Tempering
75
Surface Treatment
Polishing & Nitriding
54
Component Total
704.0
|
|||
|
Lower Punch H13 Tool Steel |
30.0 kg | 704.0 | ▼ |
|
Component Info
Dimensions
-
Material
30 kg × 5
150
Machining
Machining Subtotal
210
Heat Treatment
Hardening & Tempering
75
Surface Treatment
Polishing & Nitriding
54
Component Total
704.0
|
|||
|
Guide Plates (4 pcs) H13 Tool Steel |
12.0 kg | 332.0 | ▼ |
|
Component Info
Dimensions
-
Material
12 kg × 5
60
Machining
Machining Subtotal
140
Heat Treatment
Hardening & Tempering
30
Component Total
332.0
|
|||
|
Back Plate H13 Tool Steel |
186.0 kg | 3602.0 | ▼ |
|
Component Info
Dimensions
-
Material
186 kg × 5
930
Machining
Machining Subtotal
1110
Heat Treatment
Hardening & Tempering
465
Component Total
3602.0
|
|||
|
Cavity Blocks / Inserts (4 pcs) H11 Tool Steel |
112.0 kg | 3260.0 | ▼ |
|
Component Info
Dimensions
-
Material
112 kg × 5
560
Machining
Machining Subtotal
1225
Heat Treatment
Hardening & Tempering
280
Surface Treatment
Polishing & Nitriding
202
Component Total
3260.0
|
|||
|
Pilot Pins (8 pcs) Alloy Steel |
2.0 kg | 102.0 | ▼ |
|
Component Info
Dimensions
Ø16–25 mm
Material
2 kg × 5
10
Machining
Machining Subtotal
60
Component Total
102.0
|
|||
|
Guide Bushings Hardened Steel |
3.0 kg | 199.0 | ▼ |
|
Component Info
Dimensions
Ø12–20 mm
Material
3 kg × 5
15
Machining
Machining Subtotal
115
Heat Treatment
Hardening & Tempering
8
Component Total
199.0
|
|||
|
Compression Springs Spring Steel |
1.0 kg | 44.0 | ▼ |
|
Component Info
Dimensions
Wire Ø12 mm
Material
1 kg × 5
5
Machining
Machining Subtotal
25
Component Total
44.0
|
|||
|
Dowel / Lock Pins Alloy Steel |
1.0 kg | 94.0 | ▼ |
|
Component Info
Dimensions
Ø12–16 mm
Material
1 kg × 5
5
Machining
Machining Subtotal
60
Component Total
94.0
|
|||
|
Fasteners & Bolts Alloy Steel |
2.0 kg | 52.0 | ▼ |
|
Component Info
Dimensions
M12–M20
Material
2 kg × 5
10
Machining
Machining Subtotal
25
Component Total
52.0
|
|||
|
Design & Engineering N/A |
0.0 kg | 1654.0 | ▼ |
|
Component Info
Dimensions
25 hours
Labor
25 hrs × 50
1250
Component Total
1654.0
|
|||
|
Quality & Inspection N/A |
0.0 kg | 67.0 | ▼ |
|
Component Info
Dimensions
1 hours
Labor
1 hrs × 50
50
Component Total
67.0
|
|||
|
Tool Assembly & Tryout N/A |
0.0 kg | 1058.0 | ▼ |
|
Component Info
Dimensions
16 hours
Labor
16 hrs × 50
800
Component Total
1058.0
|
|||
